2SD2695(T6CANO,A,F
lmages are for reference only.2SD2695(T6CANO,A,F
TRANS NPN 60V 2A TO-92MOD
DatasheetTO-226-3, TO-92-3 Long Body
81,366 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor NPN 60 V 2 A 100MHz 900 mW Through Hole TO-92MOD
2SD2695(T6CANO,A,F
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | 2 A |
| Voltage - Collector Emitter Breakdown (Max) | 60 V |
| Vce Saturation (Max) @ Ib, Ic | 1.5V @ 1mA, 1A |
| Current - Collector Cutoff (Max) | 10µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 2000 @ 1A, 2V |
| Power - Max | 900 mW |
| Frequency - Transition | 100MHz |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-226-3, TO-92-3 Long Body |
| Supplier Device Package | TO-92MOD |
| Base Product Number | 2SD2695 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | 2SD2695(T6CNO,A,F) | 2SD05920RA | 2SD0592ARA | 2SD0601A0L |
| Manufacturer | Toshiba Semiconductor and Storage | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| RoHS Status | ||||
| Description | TRANS NPN 60V 2A TO-92MOD | TRANS NPN 25V 1A TO-92-B1 | TRANS NPN 50V 1A TO-92-B1 | TRANS NPN 50V 0.1A MINI3-G1 |
| Series | - | - | - | - |
| Packaging | Bulk | Cut Tape (CT)-->Tape & Box (TB) | Cut Tape (CT)-->Tape & Box (TB) | Tape & Reel (TR)-->Cut Tape (CT) |
