ADP3650JCPZ-RL
lmages are for reference only.ADP3650JCPZ-RL
IC GATE DRVR HALF-BRIDGE 8LFCSP
Datasheet8-VFDFN Exposed Pad, CSP
80,568 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 8-LFCSP-VD (3x3)
ADP3650JCPZ-RL
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 4.15V ~ 13.2V |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | - |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 20ns, 16ns |
| Operating Temperature | 0°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-VFDFN Exposed Pad, CSP |
| Supplier Device Package | 8-LFCSP-VD (3x3) |
| Base Product Number | ADP3650 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ADP3650JRZ | ADP3650JRZ-RL | ADP31100001RZ | ADP31100001RZ-AD |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | onsemi | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | Not applicable | Not applicable |
| Description | IC GATE DRVR HALF-BRIDGE 8SOIC | IC GATE DRVR HALF-BRIDGE 8SOIC | 2 12V FET DRIVER | 2 12V FET DRIVER |
| Series | - | - | * | * |
| Packaging | Tube | Tape & Reel (TR) | Bulk | Bulk |
