B32613A8472J008
lmages are for reference only.B32613A8472J008
CAP FILM 4700PF 5% 2KVDC RADIAL
DatasheetRadial
78,605 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
4700 pF Film Capacitor 1000V (1kV) 2000V (2kV) Polypropylene (PP), Metallized Radial
B32613A8472J008
| Category | Capacitors - Film Capacitors - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | B32613 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 4700 pF |
| Tolerance | ±5% |
| Voltage Rating - AC | 1000V (1kV) |
| Voltage Rating - DC | 2000V (2kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.043" L x 0.335" W (26.50mm x 8.50mm) |
| Height - Seated (Max) | 0.650" (16.50mm) |
| Termination | PC Pins - Long Leads |
| Lead Spacing | 0.886" (22.50mm) |
| Applications | DC Link, DC Filtering; High Pulse, DV/DT |
| Ratings | - |
| Features | - |
| ESR (Equivalent Series Resistance) | - |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | B32612A1103J008 | B32612A1103J008 | B32612A1153J008 | B32612A2332J008 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 10000PF 5% 1.6KVDC RAD | CAP FILM 10000PF 5% 1.6KVDC RAD | CAP FILM 0.015UF 5% 1.6KVDC RAD | CAP FILM 3300PF 5% 2KVDC RADIAL |
| Series | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| Packaging | Bulk | Bulk | Bulk | Bulk |
