B41605A5688M002
lmages are for reference only.B41605A5688M002
CAP ALUM 6800UF 20% 25V SNAP TH
DatasheetRadial, Can - Snap-In - 3 Lead
35,310 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
6800 µF 25 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 3 Lead 19mOhm @ 100Hz 5000 Hrs @ 125°C
B41605A5688M002
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | B41605 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 19mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Automotive |
| Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | 6.9 A @ 10 kHz |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.575" (40.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 3 Lead |
| Base Product Number | - |
| Impedance | 15 mOhms |
| Product Attribute | |
 |
 |
|
| Part Number | B41605A5688M009 | B41605A5688M1 | B41605A5688M2S1 | B41605A5688M8 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | |||
| Description | CAP ALUM 6800UF 20% 25V RADIAL | CAP ALUM 6800UF 20% 25V TH | CAP ALUM 6800UF 20% 25V SNAP TH | CAP ALUM 6800UF 20% 25V RADIAL |
| Series | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| Packaging | Tray | Bulk | Bulk | Bulk |
