CVHD-950X-100
lmages are for reference only.CVHD-950X-100
XTAL OSC VCXO 100.0000MHZ CMOS
Datasheet4-SMD, No Lead
66,921 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
100 MHz VCXO CMOS Oscillator 3.3V 4-SMD, No Lead
CVHD-950X-100
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | Crystek Corporation |
| Series | CVHD-950 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | VCXO |
| Frequency | 100 MHz |
| Function | - |
| Output | CMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | - |
| Absolute Pull Range (APR) | ±20ppm |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 25mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.559" L x 0.360" W (14.20mm x 9.14mm) |
| Height - Seated (Max) | 0.209" (5.30mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | CVHD-950X-122.880 | CVHD-950-100.000 | CVHD-950-122.880 | CVHD-950-125.000 |
| Manufacturer | Crystek Corporation | Crystek Corporation | Crystek Corporation | Crystek Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC VCXO 122.8800MHZ CMOS | XTAL OSC VCXO 100.0000MHZ CMOS | XTAL OSC VCXO 122.8800MHZ CMOS | XTAL OSC VCXO 125.0000MHZ CMOS |
| Series | Crystek Corporation | Crystek Corporation | Crystek Corporation | Crystek Corporation |
| Packaging | Strip | Strip | Strip | Strip |
