HCF4093M013TR
lmages are for reference only.HCF4093M013TR
IC GATE NAND SCHMIT 4CH 2IN 14SO
Datasheet14-SOIC (0.154", 3.90mm Width)
18,438 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
NAND Gate IC 4 Channel Schmitt Trigger 14-SO
HCF4093M013TR
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | STMicroelectronics |
| Series | 4000 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | HCF4093 |
| Logic Type | NAND Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | Schmitt Trigger |
| Voltage - Supply | 3V ~ 20V |
| Current - Quiescent (Max) | 20 µA |
| Current - Output High, Low | 6.8mA, 6.8mA |
| Input Logic Level - Low | 0.9V ~ 4V |
| Input Logic Level - High | 3.6V ~ 10.8V |
| Max Propagation Delay @ V, Max CL | 130ns @ 15V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SO |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HCF4093BEY | HCF4093YM013TR | HCF4001BEY | HCF4001M013TR |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE NAND 4CH 2-INP 14DIP | IC GATE NAND SCHMIT 4CH 2IN 14SO | IC GATE NOR 4CH 2-INP 14DIP | IC GATE NOR 4CH 2-INP 14SO |
| Series | 4000B | 4000 | 4000B | 4000 |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
