LM3503ITL-16/NOPB
lmages are for reference only.LM3503ITL-16/NOPB
IC LED DRVR RGLTR PWM 10DSBGA
Datasheet10-WFBGA, DSBGA
18,406 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 400mA (Switch) 10-DSBGA
LM3503ITL-16/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | Yes |
| Number of Outputs | 2 |
| Voltage - Supply (Min) | 2.5V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | 16V |
| Current - Output / Channel | 400mA (Switch) |
| Frequency | 1MHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 10-WFBGA, DSBGA |
| Supplier Device Package | 10-DSBGA |
| Base Product Number | LM3503 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | LM3503ITL-16/NOPB | LM3503ITL-25/NOPB | LM3503ITL-35 | LM3503ITL-35/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | National Semiconductor | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC LED DRVR RGLTR PWM 10TUSMD | IC LED DRVR RGLTR PWM 10TUSMD | LED DRIVER, 10-SEGMENT, PBGA10 | IC LED DRVR RGLTR PWM 10TUSMD |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
