Product CatalogPart Number
LMG3522R030QRQSRQ1
Manufacturer
Texas InstrumentsDescription
LMG3522R030QRQSRQ1
Datasheet
DatasheetPackage
52-VQFN Exposed Pad
In Stock
30,451 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
LMG3522R030QRQSRQ1
LMG3522R030QRQSRQ1
lmages are for reference only.Payment Methods
Delivery Services
Power Switch/Driver 1:1 N/P-Channel 38A 52-VQFN (12x12)
Quick Inquiry
LMG3522R030QRQSRQ1
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | Low Side |
| Output Type | N/P-Channel |
| Interface | - |
| Voltage - Load | 650V |
| Voltage - Supply (Vcc/Vdd) | 7.5V ~ 18V |
| Current - Output (Max) | 38A |
| Rds On (Typ) | 26mOhm |
| Input Type | Non-Inverting |
| Features | Slew Rate Controlled, Status Flag |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Short Circuit, UVLO |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount, Wettable Flank |
| Supplier Device Package | 52-VQFN (12x12) |
| Package / Case | 52-VQFN Exposed Pad |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
