MCP1700-2802E/TO
lmages are for reference only.MCP1700-2802E/TO
IC REG LINEAR 2.8V 250MA TO92-3
DatasheetTO-226-3, TO-92-3 (TO-226AA)
49,449 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 250mA TO-92-3
MCP1700-2802E/TO
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Bag |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 2.8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.35V @ 250mA |
| Current - Output | 250mA |
| Current - Quiescent (Iq) | 4 µA |
| PSRR | 44dB (100Hz) |
| Control Features | - |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Supplier Device Package | TO-92-3 |
| Base Product Number | MCP1700 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MCP1700-1202E/TO | MCP1700-1302E/TO | MCP1700-1502E/TO | MCP1700-1802E/TO |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 1.2V 200MA TO92-3 | IC REG LINEAR 1.3V 200MA TO92-3 | IC REG LINEAR 1.5V 200MA TO92-3 | IC REG LINEAR 1.8V 200MA TO92-3 |
| Series | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Packaging | Bag | Bag | Bag | Bag |
