SG1526J-883B
lmages are for reference only.SG1526J-883B
IC REG CTRLR BUCK/FLYBACK 18JDIP
Datasheet18-DIP (0.300", 7.62mm)
59,516 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck, Flyback Regulator Positive Output Step-Down, Step-Up/Step-Down DC-DC Controller IC
SG1526J-883B
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down, Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Buck, Flyback |
| Number of Outputs | 2 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 8V ~ 35V |
| Frequency - Switching | 1Hz ~ 350kHz |
| Duty Cycle (Max) | 49% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Enable, Reset, Soft Start |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 18-DIP (0.300", 7.62mm) |
| Supplier Device Package | - |
| Base Product Number | SG1526 |
| Grade | Military |
| Qualification | MIL-STD-883B |
| Product Attribute |  |
 |
 |
 |
| Part Number | SG1526BJ | SG1526BJ-883B | SG1526BJ-DESC | SG1526BL |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG CTRLR BUCK/FLYBACK 18DIP | IC REG CTRLR BUCK/FLYBACK 18JDIP | IC REG CTRLR BUCK/FLYBACK 18JDIP | VOLTAGE MODE PWMS, HIGH-RELIABIL |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tray |
