SI823H5CB-IM1
Manufacturer
Skyworks Solutions Inc.Description
5KV GATE DRIVER 14-QFN
Datasheet
DatasheetPackage
14-VDFN
In Stock
65,331 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SI823H5CB-IM1
SI823H5CB-IM1
lmages are for reference only.Payment Methods
Delivery Services
6A Gate Driver Capacitive Coupling 2500Vrms 2 Channel 14-QFN (5x5)
Quick Inquiry
SI823H5CB-IM1
Specifications
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | Skyworks Solutions Inc. |
| Series | Si823Hx |
| Packaging | Tray |
| RoHS Status | |
| Technology | Capacitive Coupling |
| Number of Channels | 2 |
| Voltage - Isolation | 2500Vrms |
| Common Mode Transient Immunity (Min) | 125kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 30ns, 30ns |
| Pulse Width Distortion (Max) | 5ns |
| Rise / Fall Time (Typ) | 12ns, 12ns (Max) |
| Current - Output High, Low | 4A, 4A |
| Current - Peak Output | 6A |
| Voltage - Forward (Vf) (Typ) | - |
| Voltage - Output Supply | 5.5V ~ 30V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 14-VDFN |
| Supplier Device Package | 14-QFN (5x5) |
| Approval Agency | CQC, CSA, UL, VDE |
| Base Product Number | SI823 |
| Current - DC Forward (If) (Max) | - |
