SIT5156AICFK-33N0-38.400000
lmages are for reference only.Payment Methods
Delivery Services
38.4 MHz TCXO Clipped Sine Wave Oscillator 3.3V 10-SMD, No Lead
SIT5156AICFK-33N0-38.400000
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | SiTime |
| Series | SiT5156, Elite Platform™ |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | MEMS |
| Type | TCXO |
| Frequency | 38.4 MHz |
| Function | - |
| Output | Clipped Sine Wave |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±500ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 53mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD, No Lead |
| Size / Dimension | 0.197" L x 0.126" W (5.00mm x 3.20mm) |
| Height - Seated (Max) | 0.042" (1.06mm) |
| Base Product Number | SIT5156 |
| Product Attribute | |
|
|
|
| Part Number | SIT5156AICFK-33N0-38.880000 | SIT5156AICFK-33N0-10.000000 | SIT5156AICFK-33N0-10.949297 | SIT5156AICFK-33N0-11.000000 |
| Manufacturer | SiTime | SiTime | SiTime | SiTime |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MEMS OSC TCXO 38.8800MHZ | MEMS OSC TCXO 10.0000MHZ | MEMS OSC TCXO 10.949297MHZ | MEMS OSC TCXO 11.0000MHZ |
| Series | SiTime | SiTime | SiTime | SiTime |
| Packaging | Strip | Strip | Strip | Strip |
