TS8P01GH
lmages are for reference only.TS8P01GH
8A, 50V, STANDARD BRIDGE RECTIFI
Datasheet4-SIP, TS-6P
62,201 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bridge Rectifier Single Phase Standard 50 V Through Hole TS-6P
TS8P01GH
| Category | Discrete Semiconductor Products - Diodes - Bridge Rectifiers |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| Diode Type | Single Phase |
| Technology | Standard |
| Voltage - Peak Reverse (Max) | 50 V |
| Current - Average Rectified (Io) | 8 A |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 8 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 50 V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP, TS-6P |
| Supplier Device Package | TS-6P |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | TS8P01G D2G | TS8P02G | TS8P02GH | TS8P03G |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | |||
| Description | BRIDGE RECT 1PHASE 50V 8A TS-6P | 8A, 100V, STANDARD BRIDGE RECTIF | 8A, 100V, STANDARD BRIDGE RECTIF | 8A, 200V, STANDARD BRIDGE RECTIF |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
