VS-GA100TS60SF
lmages are for reference only.VS-GA100TS60SF
IGBT MOD 600V 220A INT-A-PAK
DatasheetINT-A-Pak
69,156 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Module PT Half Bridge 600 V 220 A 780 W Chassis Mount INT-A-PAK
VS-GA100TS60SF
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | PT |
| Configuration | Half Bridge |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 220 A |
| Power - Max | 780 W |
| Vce(on) (Max) @ Vge, Ic | 1.28V @ 15V, 100A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 16.25 nF @ 30 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | INT-A-Pak |
| Supplier Device Package | INT-A-PAK |
| Base Product Number | GA100 |
| Product Attribute |  |
|
|
|
| Part Number | VS-GA100NA60UP | VS-GA100TS120UPBF | VS-GA200HS60S1 | VS-GA200HS60S1PBF |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT MOD 600V 100A 250W SOT227 | IGBT MOD 1200V 182A INT-A-PAK | IGBT MOD 600V 480A INT-A-PAK | IGBT MOD 600V 480A INT-A-PAK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
