ESD24VD5HE3-TP
Manufacturer
Micro Commercial CoDescription
TVS DIODES
Datasheet
DatasheetPackage
SC-79, SOD-523
In Stock
45,426 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ESD24VD5HE3-TP
ESD24VD5HE3-TP
lmages are for reference only.Payment Methods
Delivery Services
44V Clamp 7A (8/20µs) Ipp Tvs Diode Surface Mount SOD-523
Quick Inquiry
ESD24VD5HE3-TP
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 24V (Max) |
| Voltage - Breakdown (Min) | 26.7V |
| Voltage - Clamping (Max) @ Ipp | 44V |
| Current - Peak Pulse (10/1000µs) | 7A (8/20µs) |
| Power - Peak Pulse | 300W |
| Power Line Protection | No |
| Applications | - |
| Capacitance @ Frequency | 36pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-79, SOD-523 |
| Supplier Device Package | SOD-523 |
| Base Product Number | - |
| Unidirectional Channels | 1 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | ESD24VD5-TP | ESD200B1CSP0201XTSA1 | ESD201-B2-03LRHE6327 | ESD201B203LRHE6327XTSA1 |
| Manufacturer | Micro Commercial Co | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | Not applicable | |
| Description | TVS DIODE 24VWM 44VC SOD523 | TVS DIODE 5.5VWM 13VC | TRANS VOLTAGE SUPPRESSOR DIODE | TVS DIODE 5.5VWM 12.1VC TSLP-3 |
| Series | Micro Commercial Co | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
