LP5522TM
lmages are for reference only.LP5522TM
IC LED DRIVER LINEAR 20MA 6DSBGA
Datasheet6-WFBGA, DSBGA
46,979 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output Linear Dimming 20mA 6-DSBGA (1.44x1.16)
LP5522TM
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Linear |
| Topology | - |
| Internal Switch(s) | Yes |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | 2.7V ~ 5.5V |
| Current - Output / Channel | 20mA |
| Frequency | - |
| Dimming | - |
| Applications | - |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 6-WFBGA, DSBGA |
| Supplier Device Package | 6-DSBGA (1.44x1.16) |
| Base Product Number | LP5522 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LP5522TM/NOPB | LP5522TMX/NOPB | LP5520TL/NOPB | LP5520TLX/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRIVER LINEAR 20MA 6DSBGA | IC LED DRIVER LINEAR 20MA 6DSBGA | IC LED DRV RGLTR PWM 60MA 25USMD | IC LED DRV RGLTR PWM 60MA 25USMD |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
