VS-GT55NA120UX
lmages are for reference only.VS-GT55NA120UX
SOT-227 - HIGH SIDE CHOPPER IGBT
DatasheetSOT-227-4, miniBLOC
36,614 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Module Trench Field Stop Single Chopper 1200 V 68 A 291 W Chassis Mount SOT-227
VS-GT55NA120UX
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Configuration | Single Chopper |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 68 A |
| Power - Max | 291 W |
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 50A |
| Current - Collector Cutoff (Max) | 50 µA |
| Input Capacitance (Cies) @ Vce | - |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | SOT-227-4, miniBLOC |
| Supplier Device Package | SOT-227 |
| Base Product Number | - |
| Product Attribute |  |
|
|
|
| Part Number | VS-GA100NA60UP | VS-GA100TS120UPBF | VS-GA100TS60SF | VS-GA200HS60S1 |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT MOD 600V 100A 250W SOT227 | IGBT MOD 1200V 182A INT-A-PAK | IGBT MOD 600V 220A INT-A-PAK | IGBT MOD 600V 480A INT-A-PAK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
