VS-GB100DA60UP
lmages are for reference only.VS-GB100DA60UP
IGBT MOD 600V 125A 447W SOT227
DatasheetSOT-227-4, miniBLOC
64,793 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Module Single 600 V 125 A 447 W Chassis Mount SOT-227
VS-GB100DA60UP
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Single |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 125 A |
| Power - Max | 447 W |
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 100A |
| Current - Collector Cutoff (Max) | 100 µA |
| Input Capacitance (Cies) @ Vce | - |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | SOT-227-4, miniBLOC |
| Supplier Device Package | SOT-227 |
| Base Product Number | GB100 |
| Product Attribute |  |
|
 |
|
| Part Number | VS-GB100LH120N | VS-GB100LP120N | VS-GB100NH120N | VS-GB100TH120N |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT MOD 1200V 200A INT-A-PAK | IGBT MOD 1200V 200A INT-A-PAK | IGBT MOD 1200V 200A INT-A-PAK | IGBT MOD 1200V 200A INT-A-PAK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
