VS-GB300AH120N
lmages are for reference only.VS-GB300AH120N
IGBT MOD 1200V 620A INT-A-PAK
DatasheetDouble INT-A-PAK (5)
19,012 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Module Single 1200 V 620 A 2500 W Chassis Mount Double INT-A-PAK
VS-GB300AH120N
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Single |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 620 A |
| Power - Max | 2500 W |
| Vce(on) (Max) @ Vge, Ic | 1.9V @ 15V, 300A (Typ) |
| Current - Collector Cutoff (Max) | 5 mA |
| Input Capacitance (Cies) @ Vce | 21 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Double INT-A-PAK (5) |
| Supplier Device Package | Double INT-A-PAK |
| Base Product Number | GB300 |
| Product Attribute |  |
 |
 |
|
| Part Number | VS-GB300LH120N | VS-GB300TH120N | VS-GA100NA60UP | VS-GA100TS120UPBF |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT MOD 1200V 500A INT-A-PAK | IGBT MOD 1200V 500A INT-A-PAK | IGBT MOD 600V 100A 250W SOT227 | IGBT MOD 1200V 182A INT-A-PAK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
