VS-GB15XP120KTPBF
lmages are for reference only.VS-GB15XP120KTPBF
IGBT MODULE 1200V 30A 187W MTP
Datasheet12-MTP Module
61,130 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Module NPT Three Phase Inverter 1200 V 30 A 187 W Chassis Mount MTP
VS-GB15XP120KTPBF
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | NPT |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 30 A |
| Power - Max | 187 W |
| Vce(on) (Max) @ Vge, Ic | 3.66V @ 15V, 30A |
| Current - Collector Cutoff (Max) | 250 µA |
| Input Capacitance (Cies) @ Vce | 1.95 nF @ 30 V |
| Input | Standard |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | 12-MTP Module |
| Supplier Device Package | MTP |
| Base Product Number | GB15 |
| Product Attribute |  |
|
|
 |
| Part Number | VS-GB150TH120N | VS-GB150YG120NT | VS-150MT060WDF | VS-CPV364M4KPBF |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IGBT MOD 1200V 300A INT-A-PAK | IGBT MOD 1200V 182A ECONO3 4PACK | IGBT MOD 600V 138A 12MTP PRESS | IGBT MODULE 600V 24A 63W IMS-2 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Tube | Bulk |
