0.3 PSI-G-CGRADE-MINI
lmages are for reference only.0.3 PSI-G-CGRADE-MINI
SENSOR 0.3PSIG .02V
Datasheet4-SIP Module
55,858 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 0.3PSI (2.07kPa) Vented Gauge 0 mV ~ 20 mV (12V) 4-SIP Module
0.3 PSI-G-CGRADE-MINI
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Amphenol All Sensors Corporation |
| Series | ACPC |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Base Product Number | G-CGRADE-MINI |
| Applications | Board Mount |
| Pressure Type | Vented Gauge |
| Operating Pressure | 0.3PSI (2.07kPa) |
| Output Type | Wheatstone Bridge |
| Output | 0 mV ~ 20 mV (12V) |
| Accuracy | ±1% |
| Voltage - Supply | 16V |
| Port Size | - |
| Port Style | No Port |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | 3PSI (20.68kPa) |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP Module |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
|
| Part Number | 0.3 PSI-G-CGRADE-MINI | 0.3 PSI-D-4V | 0.3 PSI-D-4V-MIL | 0.3 PSI-D-4V-MIL |
| Manufacturer | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | SENSOR 0.3PSIG .02V | SENSOR 0.3PSID 0.19" 4.25V | SENSOR 0.3PSID 0.19" 4.25V | SENSOR 0.3PSID 0.19" 4.25V |
| Series | ACPC | AXCA | AXCA | AXCA |
| Packaging | Tube | Tube | Tube | Tube |
