Product CatalogPart Number
0447641801
Manufacturer
MolexDescription
CONN RCPT 18P 0.118 TIN PCB R/A
Datasheet
DatasheetPackage
-
In Stock
56,889 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
0447641801
0447641801
lmages are for reference only.Payment Methods
Delivery Services
18 Position Receptacle Connector 0.118" (3.00mm) Through Hole, Right Angle Tin
Quick Inquiry
0447641801
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Receptacles-Female Sockets |
| Manufacturer | Molex |
| Series | Micro-Fit 3.0 BMI 44764 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Style | Board to Board or Cable |
| Number of Positions | 18 |
| Number of Positions Loaded | All |
| Pitch - Mating | 0.118" (3.00mm) |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.118" (3.00mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | 40.0µin (1.02µm) |
| Insulation Color | Black |
| Insulation Height | 0.402" (10.20mm) |
| Contact Length - Post | 0.155" (3.94mm) |
| Operating Temperature | -40°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish - Post | Tin |
| Mated Stacking Heights | - |
| Ingress Protection | - |
| Features | Blind Mating, Board Guide |
| Current Rating (Amps) | 5A |
| Voltage Rating | 600VAC |
| Applications | General Purpose, Telecommunications |
| Insulation Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Contact Shape | Square |
| Contact Material | Phosphor Bronze |
| Contact Finish Thickness - Post | 40.0µin (1.02µm) |
| Base Product Number | 044764 |
