Product CatalogPart Number
0760553614
Manufacturer
MolexDescription
CONN HEADER IMPACT 240POS PCB
Datasheet
DatasheetPackage
-
In Stock
81,683 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
0760553614
0760553614
lmages are for reference only.Payment Methods
Delivery Services
240 Connector Header, Male Pins Through Hole Black Impact, Guide Left
Quick Inquiry
0760553614
Specifications
| Category | Connectors, Interconnects - Backplane Connectors - Specialized |
| Manufacturer | Molex |
| Series | Impact 76055 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Connector Usage | - |
| Connector Type | Header, Male Pins |
| Connector Style | Impact, Guide Left |
| Number of Positions | 240 |
| Number of Positions Loaded | All |
| Pitch | 0.053" (1.35mm) |
| Number of Rows | 15 |
| Number of Columns | 16 |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Contact Layout, Typical | 80 Differential Pairs |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Color | Black |
| Current Rating (Amps) | - |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -55°C ~ 85°C |
| Voltage Rating | 30V |
| Base Product Number | 076055 |
