Product CatalogPart Number
0805LS-182XJRC
Manufacturer
CoilcraftDescription
RF INDUCTOR, FERRITE CORE, 5% TO
Datasheet
DatasheetPackage
0805 (2012 Metric)
In Stock
44,670 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
0805LS-182XJRC
0805LS-182XJRC
lmages are for reference only.Payment Methods
Delivery Services
1.8 µH Unshielded Wirewound Inductor 410 mA 1.15Ohm Max 0805 (2012 Metric)
Quick Inquiry
0805LS-182XJRC
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Coilcraft |
| Series | 0805LS |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | Ceramic, Ferrite |
| Inductance | 1.8 µH |
| Tolerance | ±5% |
| Current Rating (Amps) | 410 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 1.15Ohm Max |
| Q @ Freq | 20 @ 7.9MHz |
| Frequency - Self Resonant | 246MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 100°C |
| Inductance Frequency - Test | 7.9 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 |
| Size / Dimension | 0.090" L x 0.075" W (2.29mm x 1.91mm) |
| Height - Seated (Max) | 0.063" (1.60mm) |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | 0805LS-182XGRC | 0805LS-102XGRC | 0805LS-102XJRC | 0805LS-103XGRC |
| Manufacturer | Coilcraft | Coilcraft | Coilcraft | Coilcraft |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RF INDUCTOR, FERRITE CORE, 2% TO | RF INDUCTOR, FERRITE CORE, 2% TO | RF INDUCTOR, FERRITE CORE, 5% TO | RF INDUCTOR, FERRITE CORE, 2% TO |
| Series | Coilcraft | Coilcraft | Coilcraft | Coilcraft |
| Packaging | Strip | Strip | Strip | Strip |
