101C224U050DN2D
lmages are for reference only.101C224U050DN2D
CAP ALUM 50V POLAR
DatasheetRadial, Can - Screw Terminals
78,850 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
220 mF 50 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 3.5mOhm @ 120Hz 5000 Hrs @ 105°C
101C224U050DN2D
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Cornell Dubilier Knowles |
| Series | 101C |
| Packaging | Bulk |
| RoHS Status | |
| Capacitance | 220 mF |
| Tolerance | -10%, +75% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 3.5mOhm @ 120Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | High Temperature Reflow |
| Ripple Current @ Low Frequency | 63 A @ 120 Hz |
| Ripple Current @ High Frequency | 66.15 A @ 10 kHz |
| Lead Spacing | 1.250" (31.75mm) |
| Size / Dimension | 3.000" Dia (76.20mm) |
| Height - Seated (Max) | 7.687" (195.25mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Base Product Number | - |
| Impedance | - |
| Product Attribute | |
 |
|
|
| Part Number | 101C212U075AK2B | 101C213U040AJ2B | 101C213U063EJ1A | 101C214U040DP2D |
| Manufacturer | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| RoHS Status | ROHS3 Compliant | |||
| Description | CAP ALUM SCREW CHAS MT | CAP ALUM 40V POLAR | CAP ALUM 63V POLAR | CAP ALUM 40V POLAR |
| Series | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| Packaging | Bulk | Bulk | Bulk | Bulk |
