105HC3600K4VM6
lmages are for reference only.105HC3600K4VM6
CAP FILM 1UF 10% 600VAC CHAS MT
DatasheetNonstandard
70,178 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 µF Film Capacitor 600V Polypropylene (PP) Nonstandard
105HC3600K4VM6
| Category | Capacitors - Film Capacitors - |
| Manufacturer | Cornell Dubilier Knowles |
| Series | HC3 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 1 µF |
| Tolerance | ±10% |
| Voltage Rating - AC | 600V |
| Voltage Rating - DC | - |
| Dielectric Material | Polypropylene (PP) |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 2.953" L x 1.969" W (75.00mm x 50.00mm) |
| Height - Seated (Max) | 1.193" (30.30mm) |
| Termination | Threaded, Female |
| Lead Spacing | - |
| Applications | Conduction Cooled; High Pulse, DV/DT |
| Ratings | - |
| Features | - |
| ESR (Equivalent Series Resistance) | 0.5 mOhms |
| Base Product Number | - |
| Product Attribute |  |
 |
|
 |
| Part Number | 105HC3600K2EM8 | 105HC3600K4TM6 | 105HC3600K4TM6 | 105HC3B600K2SM6 |
| Manufacturer | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 1UF 10% 600VAC CHAS MT | CAP FILM 1UF 10% 600VAC CHAS MT | CAP FILM 1UF 10% 600VAC CHAS MT | CAP FILM 1UF 10% 600VAC CHASSIS |
| Series | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| Packaging | Bulk | Bulk | Bulk | Bulk |
