12LRS225C
lmages are for reference only.12LRS225C
FIXED IND 2.2MH 280MA 4.6 OHM TH
DatasheetRadial, Vertical Cylinder, 4 Leads
10,982 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.2 mH Shielded Wirewound Inductor 280 mA 4.6Ohm Max Radial, Vertical Cylinder, 4 Leads
12LRS225C
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Murata Power Solutions Inc. |
| Series | 1200LRS |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 2.2 mH |
| Tolerance | ±15% |
| Current Rating (Amps) | 280 mA |
| Current - Saturation (Isat) | - |
| Shielding | Shielded |
| DC Resistance (DCR) | 4.6Ohm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder, 4 Leads |
| Supplier Device Package | - |
| Size / Dimension | 0.413" Dia (10.50mm) |
| Height - Seated (Max) | 0.335" (8.50mm) |
| Base Product Number | 12LRS |
| Product Attribute |  |
 |
|
 |
| Part Number | 12LRS223C | 12LRS224C | 12LRS224C | 12LRS226C |
| Manufacturer | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 22UH 2.6A 90 MOHM TH | FIXED IND 220UH 780MA 540MOHM TH | FIXED IND 220UH 780MA 540MOHM TH | FIXED IND 22MH 73MA 70 OHM TH |
| Series | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. |
| Packaging | Bulk | Bulk | Bulk | Bulk |
