Part Number
1415542-9
Manufacturer
TE Connectivity Potter & Brumfield RelaysDescription
RELAY GEN PURP
Datasheet
Datasheet
Package
-
In Stock
68,298 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
1415542-9
lmages are for reference only.1415542-9
RELAY GEN PURP
-
68,298 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) 230VAC Coil Chassis Mount
1415542-9
Category | Relays - Power Relays-Over 2 Amps - |
Manufacturer | TE Connectivity Potter & Brumfield Relays |
Series | RM, SCHRACK |
Packaging | Bulk |
RoHS Status | ROHS3 Compliant |
Mounting Type | Chassis Mount |
Coil Voltage | 230VAC |
Contact Form | DPDT (2 Form C) |
Contact Rating (Current) | 16 A |
Switching Voltage | 440VAC - Max |
Load - Max Switching | 7040VA |
Coil Current | 27.7 mA |
Coil Type | Non Latching |
Features | Mechanical Indicator |
Termination Style | Quick Connect - 0.250" (6.3mm) |
Seal Rating | - |
Coil Insulation | Class B |
Must Operate Voltage | 195.5 VAC |
Must Release Voltage | 23 VAC |
Operate Time | 15 ms |
Release Time | 10 ms |
Operating Temperature | -40°C ~ 70°C |
Contact Material | Silver Nickel (AgNi) |
Approval Agency | cURus, VDE |
Relay Type | General Purpose |
Grade | - |
Qualification | - |
Coil Resistance | 8.3 kOhms |
Base Product Number | RM2257 |
