1571262-3
lmages are for reference only.1571262-3
SWITCH TACTILE SPST-NO 0.05A 12V
Datasheet-
52,466 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Tactile Switch SPST-NO Side Actuated Surface Mount, Right Angle
1571262-3
| Category | Switches - Tactile Switches - |
| Manufacturer | TE Connectivity ALCOSWITCH Switches |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Circuit | SPST-NO |
| Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.05A @ 12VDC |
| Actuator Type | Rectangular Button |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Height off PCB, Vertical | - |
| Actuator Length, Right Angle | - |
| Actuator Orientation | Side Actuated |
| Termination Style | Gull Wing |
| Outline | 5.40mm x 5.60mm |
| Illumination | Non-Illuminated |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
| Operating Force | 220gf |
| Ingress Protection | - |
| Features | Board Guide |
| Operating Temperature | -20°C ~ 70°C |
| Actuator Material | Liquid Crystal Polymer (LCP) |
| Switch Travel | - |
| Mechanical Life | 50,000 Cycles |
| Base Product Number | 1571262 |
| Product Attribute |  |
 |
 |
|
| Part Number | 1571262-1 | 1571262-2 | 1571262-4 | 1571185-1 |
| Manufacturer | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | SWITCH TACTILE SPST-NO 0.05A 12V | SWITCH TACTILE SPST-NO 0.05A 12V | SWITCH TACTILE SPST-NO 0.05A 12V | SWITCH TACTILE SPST-NO 0.05A 12V |
| Series | - | - | - | FSMCD |
| Packaging | Bag | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT)--> | Bulk |
