1617076-9
lmages are for reference only.1617076-9
RELAY GENERAL PURPOSE 4PDT 2A 6V
Datasheet-
57,418 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay 4PDT (4 Form C) Through Hole
1617076-9
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | 3SBH |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 6VDC |
| Contact Form | 4PDT (4 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 115VAC, 28VDC - Max |
| Load - Max Switching | - |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Hermetically |
| Coil Insulation | - |
| Must Operate Voltage | - |
| Must Release Voltage | - |
| Operate Time | 4 ms |
| Release Time | 6 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | - |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Base Product Number | 1617076 |
| Coil Current | 214.3 mA |
| Coil Resistance | 28 Ohms |
| Product Attribute | |
|
|
|
| Part Number | 1617076-2 | 1617076-3 | 1617076-5 | 1617076-6 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | RELAY GENERAL PURPOSE 4PDT 2A | RELAY GENERAL PURPOSE 4PDT 2A | RELAY GENERAL PURPOSE 4PDT 2A | RELAY GENERAL PURPOSE 4PDT 2A |
| Series | 3SBH, CII | 3SBH, CII | 3SBH, CII | 3SBH, CII |
| Packaging | Bulk | Bulk | Bulk | Bulk |
