170M5498
lmages are for reference only.170M5498
FUSE SQUARE 800A 1.3KVAC RECT
DatasheetRectangular, Blade
46,448 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
800A 1.3 kVAC Fuse Square Requires Holder
170M5498
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Eaton - Bussmann Electrical Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Mounting Type | Requires Holder |
| Fuse Type | Square |
| Current Rating (Amps) | 800A |
| Voltage Rating - AC | 1.3 kVAC |
| Response Time | - |
| Applications | Electrical, Industrial |
| Features | Indicating |
| Class | - |
| Approval Agency | CSA, UR |
| Operating Temperature | - |
| Breaking Capacity @ Rated Voltage | 100kA |
| Package / Case | Rectangular, Blade |
| Size / Dimension | 3.150" L x 2.402" W x 3.032" H (80.00mm x 61.00mm x 77.00mm) |
| Base Product Number | - |
| Voltage Rating - DC | - |
| Grade | - |
| Qualification | - |
| Melting I²t | 245000.0 |
| DC Cold Resistance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 170M5496 | 170M5497 | 170M5499 | 170M5138 |
| Manufacturer | Eaton - Bussmann Electrical Division | Eaton - Bussmann Electrical Division | Eaton - Bussmann Electrical Division | Eaton - Bussmann Electrical Division |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | FUSE SQUARE 630A 1.3KVAC RECT | FUSE SQUARE 700A 1.3KVAC RECT | FUSE SQUARE 900A 1.3KVAC RECT | FUSE SQUARE 250A 1.3KVAC RECT |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
