1825013-6
lmages are for reference only.1825013-6
SW ROTARY DIP BCD COMP 0.4VA 20V
Datasheet-
50,822 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Dip Switch BCD Complement 10 Position Surface Mount Rotary for Tool Actuator 0.4VA 20VAC/DC
1825013-6
| Category | Switches - DIP Switches - |
| Manufacturer | TE Connectivity ALCOSWITCH Switches |
| Series | MRD |
| Packaging | Tape & Reel (TR) |
| RoHS Status | Not applicable |
| Circuit | BCD Complement |
| Number of Positions | 10 |
| Current Rating (Amps) | 0.4VA |
| Voltage Rating | 20VAC/DC |
| Actuator Type | Rotary for Tool |
| Actuator Level | Flush, Recessed |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Height Above Board | 0.122" (3.10mm) |
| Mounting Type | Surface Mount |
| Termination Style | Gull Wing |
| Pitch | 0.100" (2.54mm), Full |
| Washable | No |
| Features | Process Sealed |
| Operating Temperature | -30°C ~ 85°C |
| Body Material | Polyphenylene Sulfide (PPS) |
| Length | 0.276" (7.00mm) |
| Mechanical Life | 20,000 Steps |
| Electrical Life | 10,000 Steps |
| Base Product Number | 1825013 |
| Product Attribute | |
|
|
|
| Part Number | 1825013-1 | 1825013-2 | 1825013-7 | 1825013-9 |
| Manufacturer | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches |
| RoHS Status | ROHS3 Compliant | Not applicable | Not applicable | Not applicable |
| Description | SWITCH ROTARY DIP BCD 0.4VA 20V | SW ROTARY DIP BCD COMP 0.4VA 20V | SWITCH ROTARY DIP BCD 0.4VA 20V | SWITCH ROTARY DIP BCD 0.4VA 20V |
| Series | MRD | MRD | MRD | MRD |
| Packaging | Tube | Tube | Tube | Tube |
