1N4764A
lmages are for reference only.1N4764A
DIODE ZENER 100V 1W DO204AL
DatasheetDO-204AL, DO-41, Axial
70,323 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Zener Diode 100 V 1 W ±5% Through Hole DO-204AL (DO-41)
1N4764A
| Category | Discrete Semiconductor Products - Diodes - Zener |
| Manufacturer | Good-Ark Semiconductor |
| Series | - |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Voltage - Zener (Nom) (Vz) | 100 V |
| Tolerance | ±5% |
| Power - Max | 1 W |
| Impedance (Max) (Zzt) | 350 Ohms |
| Current - Reverse Leakage @ Vr | 5 µA @ 76 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 200 mA |
| Operating Temperature | 200°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) |
| Base Product Number | - |
| Product Attribute |  |
|
|
|
| Part Number | 1N4764 BK TIN/LEAD | 1N4764 G | 1N4764A | 1N4764A |
| Manufacturer | Central Semiconductor Corp | Microsemi Corporation | SMC Diode Solutions | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | THROUGH-HOLE-DIODE-ZENER | DIODE ZENER 100V 1W DO204AL | DIODE ZENER 100V 1W DO41 | DIODE ZENER 100V 1W DO204AL |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Tape & Box (TB) | Tape & Reel (TR) |
