Product CatalogPart Number
1N966B
Manufacturer
MotorolaDescription
DIODE ZENER 16V 500MW DO204AH
Datasheet
DatasheetPackage
DO-204AH, DO-35, Axial
In Stock
46,449 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
1N966B
1N966B
lmages are for reference only.Payment Methods
Delivery Services
Zener Diode 16 V 500 mW ±5% Through Hole DO-204AH (DO-35)
Quick Inquiry
1N966B
Specifications
| Category | Discrete Semiconductor Products - Diodes - Zener |
| Manufacturer | Motorola |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Voltage - Zener (Nom) (Vz) | 16 V |
| Tolerance | ±5% |
| Power - Max | 500 mW |
| Impedance (Max) (Zzt) | 17 Ohms |
| Current - Reverse Leakage @ Vr | 5 µA @ 12.2 V |
| Voltage - Forward (Vf) (Max) @ If | - |
| Operating Temperature | -65°C ~ 200°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | DO-204AH, DO-35, Axial |
| Supplier Device Package | DO-204AH (DO-35) |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
|
|
|
| Part Number | 1N966A | 1N966B | 1N966B | 1N966B |
| Manufacturer | Microchip Technology | onsemi | Microchip Technology | Fairchild Semiconductor |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | DIODE ZENER 16V 500MW DO7 | DIODE ZENER 16V 500MW DO35 | DIODE ZENER 16V 500MW DO7 | DIODE ZENER 16V 500MW DO204AH |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
