2-1825033-6
lmages are for reference only.2-1825033-6
SW ROTARY DIP BCD COMP 0.4VA 20V
Datasheet-
20,335 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Dip Switch BCD Complement 10 Position Through Hole Rotary with Knob Actuator 0.4VA 20VAC/DC
2-1825033-6
| Category | Switches - DIP Switches - |
| Manufacturer | TE Connectivity ALCOSWITCH Switches |
| Series | DR |
| Packaging | Tube |
| RoHS Status | Not applicable |
| Circuit | BCD Complement |
| Number of Positions | 10 |
| Current Rating (Amps) | 0.4VA |
| Voltage Rating | 20VAC/DC |
| Actuator Type | Rotary with Knob |
| Actuator Level | Raised |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Height Above Board | 0.386" (9.80mm) |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Pitch | 0.100" (2.54mm), Full |
| Washable | No |
| Features | - |
| Operating Temperature | -30°C ~ 85°C |
| Body Material | Polyphenylene Sulfide (PPS) |
| Length | 0.394" (10.00mm) |
| Mechanical Life | 20,000 Steps |
| Electrical Life | 20,000 Steps |
| Base Product Number | 1825033 |
| Product Attribute | |
|
 |
|
| Part Number | 2-1825033-1 | 2-1825007-0 | 2-1825013-0 | 2-1825058-0 |
| Manufacturer | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches | TE Connectivity ALCOSWITCH Switches |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SWITCH ROTARY DIP BCD 0.4VA 20V | SWITCH ROTARY DIP HEX 0.4VA 20V | SWITCH ROTARY DIP HEX 0.4VA 20V | SWITCH STANDARD DIP SPST |
| Series | DR | DRD | MRD | ADE |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
