2-2176086-3
lmages are for reference only.2-2176086-3
FIXED IND 13NH 870MA 140MOHM SMD
DatasheetNonstandard
94,642 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
13 nH Unshielded Wirewound Inductor 870 mA 140mOhm Max Nonstandard
2-2176086-3
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | TE Connectivity Passive Product |
| Series | 3654 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 13 nH |
| Tolerance | ±5% |
| Current Rating (Amps) | 870 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 140mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 4.2GHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 250 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.045" L x 0.028" W (1.15mm x 0.70mm) |
| Height - Seated (Max) | 0.024" (0.60mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | 2-2176086-0 | 2-2176086-1 | 2-2176086-1 | 2-2176086-2 |
| Manufacturer | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 10NH 1.3A 85 MOHM SMD | FIXED IND 11NH 1.4A 65 MOHM SMD | FIXED IND 11NH 1.4A 65 MOHM SMD | FIXED IND 12NH 870MA 90 MOHM SMD |
| Series | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
