Product CatalogPart Number
20720-020E-02
Manufacturer
I-PEXDescription
EVAFLEX 5-VS 20P
Datasheet
DatasheetPackage
-
In Stock
78,311 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
20720-020E-02
20720-020E-02
lmages are for reference only.Payment Methods
Delivery Services
20 Position FFC, FPC Connector Contacts, Top 0.020" (0.50mm) Surface Mount, Right Angle
Quick Inquiry
20720-020E-02
Specifications
| Category | Connectors, Interconnects - FFC-FPC Flat Flexible Connectors - FFC-FPC Flat Flexible Connector Assemblies |
| Manufacturer | I-PEX |
| Series | EVAFLEX® 5-VS |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top |
| Number of Positions | 20 |
| Pitch | 0.020" (0.50mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.33mm |
| Height Above Board | 0.075" (1.90mm) |
| Locking Feature | - |
| Cable End Type | Notched |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Actuator Material | - |
| Features | EMI Shielded, Solder Retention |
| Voltage Rating | 200V |
| Operating Temperature | -40°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 300mA per Contact |
| Contact Finish Thickness | 1.25µin (0.03µm) |
| Housing Color | Black |
| Actuator Color | - |
| Mating Cycles | 30 |
| Base Product Number | - |
