2425-001-X5U0-102PLF
lmages are for reference only.2425-001-X5U0-102PLF
CAP FEEDTHRU 1000PF 100V AXIAL
DatasheetAxial, Bushing, 1 Turret Lead
76,129 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1000 pF Feed Through Capacitor 100V 20 A Axial, Bushing, 1 Turret Lead
2425-001-X5U0-102PLF
| Category | Filters - Feed Through Capacitors - |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components |
| Series | 2425 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Tolerance | 0%, +100% |
| Voltage - Rated | 100V |
| Current | 20 A |
| DC Resistance (DCR) (Max) | - |
| Operating Temperature | -55°C ~ 125°C |
| Insertion Loss | - |
| Temperature Coefficient | X5U |
| Ratings | - |
| Package / Case | Axial, Bushing, 1 Turret Lead |
| Size / Dimension | 0.180" Dia x 0.359" L (4.57mm x 9.12mm) |
| Height (Max) | - |
| Thread Size | 8-32 |
| Capacitance | 1000 pF |
| Mounting Type | - |
| Base Product Number | - |
| Product Attribute | |
 |
|
|
| Part Number | 2425-001-X5U0-102AA | 2425-001-X5U0-102AALF | 2425-001-X5U0-102M | 2425-001-X5U0-102MLF |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | CAP FEEDTHRU 100V AXIAL | CAP FEEDTHRU 200V AXIAL | CAP FEEDTHRU 1000PF 20% 200V | CAP FEEDTHRU 1000PF 20% 200V |
| Series | 2425 | 2425 | 2425 | 2425 |
| Packaging | Bulk | Bulk | Bulk | Bulk |
