2450DP39G5500001E
lmages are for reference only.2450DP39G5500001E
RF DIPLEXER 2.45GHZ/5.5GHZ 1008
Datasheet1008 (2520 Metric), 6 PC Pad
93,081 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Diplexer 2.4GHz ~ 2.5GHz / 5.15GHz ~ 5.85GHz 1008 (2520 Metric), 6 PC Pad
2450DP39G5500001E
| Category | RF and Wireless - RF Multiplexers - |
| Manufacturer | Johanson Technology Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Diplexer |
| Frequency Bands (Low / High) | 2.4GHz ~ 2.5GHz / 5.15GHz ~ 5.85GHz |
| Low Band Attenuation (min / max dB) | 22.00dB / - |
| High Band Attenuation (min / max dB) | 25.00dB / - |
| Return Loss (Low Band / High Band) | -9.5dB / -9.5dB |
| Mounting Type | Surface Mount |
| Package / Case | 1008 (2520 Metric), 6 PC Pad |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | 2450DP39G5500001E | 2450DP39K5400001E | 2450DP39K5400001E | 2450DP14B7200001T |
| Manufacturer | Johanson Technology Inc. | Johanson Technology Inc. | Johanson Technology Inc. | Johanson Technology Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RF DIPLEXER 2.45GHZ/5.5GHZ 1008 | RF DIPLEXER 2.45GHZ/5.4GHZ 1008 | RF DIPLEXER 2.45GHZ/5.4GHZ 1008 | MINI PASSIVE RF DIPLEXER 2.4/7GH |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
