2964694
lmages are for reference only.2964694
SSR RELAY SPST-NO 25A 24-280V
DatasheetSSR with Integrated Heat Sink
55,862 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Solid State SPST-NO (1 Form A) SSR with Integrated Heat Sink
2964694
| Category | Relays - Solid State Relays SSR - |
| Manufacturer | Phoenix Contact |
| Series | ELR 1 |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Mounting Type | DIN Rail |
| Circuit | SPST-NO (1 Form A) |
| Output Type | AC, Zero Cross |
| Voltage - Input | 4 ~ 32VDC |
| Voltage - Load | 24 V ~ 280 V |
| Load Current | 25 A |
| Termination Style | Screw Terminal |
| Operating Temperature | -20°C ~ 80°C |
| Package / Case | SSR with Integrated Heat Sink |
| Supplier Device Package | - |
| Approval Agency | cURus |
| Grade | - |
| Qualification | - |
| Base Product Number | 296469 |
| On-State Resistance (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 2964254 | 2964270 | 2964283 | 2964296 |
| Manufacturer | Phoenix Contact | Phoenix Contact | Phoenix Contact | Phoenix Contact |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SSR RELAY SPST-NO 100MA 3-48V | SSR RELAY SPST-NO 50MA 4-30V | SSR RELAY SPST-NO 50MA 4-30V | SSR RELAY SPST-NO 3A 3-30V |
| Series | DEK-OE | DEK-OE | DEK-OE | DEK-OV |
| Packaging | Bulk | Bulk | Bulk | Bulk |
