2N7002KDW
lmages are for reference only.2N7002KDW
MOSFET 2N-CH 60V 0.115A SOT363
Datasheet6-TSSOP, SC-88, SOT-363
87,931 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 60V 115mA (Ta) 200mW (Ta) Surface Mount SOT-363
2N7002KDW
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | HY Electronic (Cayman) Limited |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 115mA (Ta) |
| Rds On (Max) @ Id, Vgs | 3Ohm @ 500mA, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 0.8nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 35pF @ 25V |
| Power - Max | 200mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SOT-363 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | 2N7002KDW-13P | 2N7002KDW-AU_R1_000A1 | 2N7002KDW-G | 2N7002KDW-HF |
| Manufacturer | Micro Commercial Co | Panjit International Inc. | Comchip Technology | Comchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | MOSFET 2N-CH 60V 0.34A SOT363 | MOSFET 2N-CH 60V 0.25A SOT363 | MOSFET 2N-CH 60V 0.34A SOT363 | MOSFET 2N-CH 60V 0.34A SOT363 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
