2SEPC100MZ
lmages are for reference only.2SEPC100MZ
CAP ALUM POLY 100UF 20% 2.5V TH
DatasheetRadial, Can
71,107 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
100 µF 2.5 V Aluminum - Polymer Capacitors Radial, Can 7mOhm 5000 Hrs @ 105°C
2SEPC100MZ
| Category | Capacitors - Aluminum Polymer Capacitors - |
| Manufacturer | Panasonic Electronic Components |
| Series | OS-CON™, SEPC |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Polymer |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 2.5 V |
| ESR (Equivalent Series Resistance) | 7mOhm |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 209 mA @ 120 Hz |
| Ripple Current @ High Frequency | 4.18 A @ 100 kHz |
| Lead Spacing | 0.079" (2.00mm) |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.354" (9.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Base Product Number | 2SEPC |
| Features | - |
| Impedance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 2SEPC1000MX | 2SEPC1000MX+S | 2SEPC100MZ+TSS | 2SEPC2700M |
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP ALUM POLY 1000UF 20% 2.5V TH | CAP ALUM POLY 1000UF 20% 2.5V TH | CAP ALUM POLY 100UF 20% 2.5V TH | CAP ALUM POLY 2700UF 20% 2.5V TH |
| Series | OS-CON™, SEPC | OS-CON™, SEPC | OS-CON™, SEPC | OS-CON™, SEPC |
| Packaging | Bulk | Cut Tape (CT)-->Tape & Box (TB) | Tape & Box (TB) | Bulk |
