2SJ606-ZK-E1-AY
lmages are for reference only.2SJ606-ZK-E1-AY
P-CHANNEL SWITCHING POWER MOSFET
DatasheetTO-263-3, D2PAK (2 Leads + Tab), TO-263AB
55,816 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 60 V 83A 120W Surface Mount TO-220SMD
2SJ606-ZK-E1-AY
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | NEC Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 83A |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 15mOhm @ 42A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 4800 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 120W |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-220SMD |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 120 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
 |
|
| Part Number | 2SJ600-Z-E1-AZ | 2SJ601(0)-Z-E1-AZ | 2SJ601-ZK-E1-AZ | 2SJ604-ZJ-E1-AZ |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | TRANSISTOR | TRANSISTOR | MP-3ZK | 2SJ604-ZJ-E1-AZ - SWITCHING P-CH |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
