3-1393812-5
lmages are for reference only.3-1393812-5
RELAY GEN PURPOSE DPDT 2A 24V
Datasheet-
35,462 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) Socketable
3-1393812-5
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | V23054, AXICOM |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Socketable |
| Coil Voltage | 24VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 125VAC, 150VDC - Max |
| Load - Max Switching | 250VA, 300W |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Plug In |
| Seal Rating | - |
| Coil Insulation | - |
| Must Operate Voltage | 10.5 VDC |
| Must Release Voltage | - |
| Operate Time | 16 ms |
| Release Time | 2 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver (Ag), Gold (Au) |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Base Product Number | 1393812 |
| Coil Current | 38.1 mA |
| Coil Resistance | 630 Ohms |
| Product Attribute | |
|
|
|
| Part Number | 3-1393812-2 | 3-1393812-3 | 3-1393810-4 | 3-1393813-0 |
| Manufacturer | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays |
| RoHS Status | Not applicable | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RELAY GEN PURP DPDT 200MA 220V | RELAY GEN PURPOSE DPDT 2A 110V | RELAY GEN PURPOSE DPDT 2A 32V | RELAY GEN PURPOSE 6PDT 2A 12.5V |
| Series | V23054, AXICOM | V23054, AXICOM | V23154, AXICOM | V23054, AXICOM |
| Packaging | Bulk | Bulk | Bulk | Bulk |
