3021-A-N-700
lmages are for reference only.3021-A-N-700
LED DRIVER CC AC/DC 32V 700MA
Datasheet7-SIP Module, 6 Leads
68,936 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
700mA 32V (Max) Constant Current LED Driver AC DC Converter Topology 1 Output
3021-A-N-700
| Category | Power Supplies - Board Mount - LED Drivers - |
| Manufacturer | LEDdynamics Inc. |
| Series | BuckPuck™ 3021 |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Type | Constant Current |
| Topology | AC DC Converter |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 7VAC |
| Voltage - Input (Max) | 24VAC |
| Voltage - Output | 32V (Max) |
| Current - Output (Max) | 700mA |
| Power (Watts) | 22 W |
| Dimming | - |
| Features | Remote On/Off, SCP |
| Operating Temperature | -40°C ~ 80°C |
| Efficiency | 95% |
| Mounting Type | Through Hole |
| Package / Case | 7-SIP Module, 6 Leads |
| Size / Dimension | 0.83" L x 0.83" W x 0.43" H (21.0mm x 21.0mm x 11.0mm) |
| Approval Agency | - |
| Weight | - |
| Base Product Number | - |
| Standard Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 3021-A-N-350 | 3021-A-N-500 | 3021-A-E-1000 | 3021-A-E-350 |
| Manufacturer | LEDdynamics Inc. | LEDdynamics Inc. | LEDdynamics Inc. | LEDdynamics Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | LED DRIVER CC AC/DC 32V 350MA | LED DRIVER CC AC/DC 32V 500MA | LED DRIVER CC AC/DC 32V 1A | LED DRIVER CC AC/DC 32V 350MA |
| Series | BuckPuck™ 3021 | BuckPuck™ 3021 | BuckPuck™ 3021 | BuckPuck™ 3021 |
| Packaging | Bulk | Bulk | Bulk | Bulk |
