RELAY GEN PURPOSE DPDT 2A 12V
Datasheet-
74,353 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) Chassis Mount
3SBC2144A2
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | 3SBC, CII |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Chassis Mount |
| Coil Voltage | 12VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 115VAC, 28VDC - Max |
| Load - Max Switching | 230VA, 56W |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Hermetically |
| Coil Insulation | - |
| Must Operate Voltage | 5.4 VDC |
| Must Release Voltage | 0.6 VDC |
| Operate Time | 4 ms |
| Release Time | 4 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | - |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | Military |
| Qualification | MIL-R-39016/13 |
| Base Product Number | 3SBC2 |
| Coil Current | 57.1 mA |
| Coil Resistance | 210 Ohms |
| Product Attribute | |
|
|
|
| Part Number | 3SBC1053A2 | 3SBC1347A2 | 3SBC1501A2 | 3SBC1502A2 |
| Manufacturer | TE Connectivity | TE Connectivity | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | Low Signal Relays - PCB 3SBC1053 | Low Signal Relays - PCB 3SBC1347 | RELAY GENERAL PURPOSE DPDT 2A 6V | RELAY GEN PURPOSE DPDT 2A 12V |
| Series | * | * | 3SBC, CII | 3SBC, CII |
| Packaging | Tray | Tray | Bulk | Bulk |
