4700-053M
lmages are for reference only.4700-053M
FILTER LC(PI) 2000PF SMD
DatasheetPill, Round
70,678 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC (Pi) EMI Filter 3rd Order Low Pass 1 Channel C = 2000pF Pill, Round
4700-053M
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components |
| Series | 4700 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | - |
| Attenuation Value | 45dB @ 100MHz |
| Resistance - Channel (Ohms) | - |
| Current | - |
| Values | C = 2000pF |
| ESD Protection | No |
| Operating Temperature | -55°C ~ 125°C |
| Applications | General Purpose |
| Voltage - Rated | 100V |
| Mounting Type | Surface Mount |
| Package / Case | Pill, Round |
| Size / Dimension | 0.085" Dia x 0.315" L (2.16mm x 8.00mm) |
| Height | - |
| Number of Channels | 1 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | 4700-053M | 4700-053MLF | 4700-053MLF | 4700-053T |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | FILTER LC(PI) 2000PF SMD | FILTER LC(PI) 2000PF SMD | FILTER LC(PI) 2000PF SMD | FILTER LC(PI) 2000PF SMD |
| Series | 4700 | 4700 | 4700 | 4700 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
