5 INCH-G-BASIC
lmages are for reference only.5 INCH-G-BASIC
SENSOR 0.18PSIG 0.08" .0225V
Datasheet4-SIP Module
50,825 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 0.18PSI (1.25kPa) Vented Gauge Male - 0.08" (2.14mm) Tube 0 mV ~ 22.5 mV (4.5V) 4-SIP Module
5 INCH-G-BASIC
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Amphenol All Sensors Corporation |
| Series | ADUX |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Base Product Number | G-BASIC |
| Applications | Board Mount |
| Pressure Type | Vented Gauge |
| Operating Pressure | 0.18PSI (1.25kPa) |
| Output Type | Wheatstone Bridge |
| Output | 0 mV ~ 22.5 mV (4.5V) |
| Accuracy | ±0.5% |
| Voltage - Supply | 6V |
| Port Size | Male - 0.08" (2.14mm) Tube |
| Port Style | Barbless |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | - |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP Module |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | 5 INCH-G-4V | 5 INCH-G-4V-90 | 5 INCH-G-4V-90 | 5 INCH-G-4V-MIL |
| Manufacturer | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | SENSOR 0.18PSIG 0.19" 4.25V | SENSOR PRESS GAUGE 5" H2O 4SIP | SENSOR PRESS GAUGE 5" H2O 4SIP | SENSOR 0.18PSIG 0.19" 4.25V |
| Series | ADCA | - | - | ADCA |
| Packaging | Tube | Tube | Tube | Tube |
