5 PSI-D-PRIME-MINI
lmages are for reference only.5 PSI-D-PRIME-MINI
SENSOR 5PSID 0.17" .06V
Datasheet4-SIP Module
53,836 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 5PSI (34.47kPa) Differential Male - 0.17" (4.34mm) Tube, Dual 0 mV ~ 60 mV (12V) 4-SIP Module
5 PSI-D-PRIME-MINI
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Amphenol All Sensors Corporation |
| Series | ACPC |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Base Product Number | D-PRIME-MINI |
| Applications | Board Mount |
| Pressure Type | Differential |
| Operating Pressure | 5PSI (34.47kPa) |
| Output Type | Wheatstone Bridge |
| Output | 0 mV ~ 60 mV (12V) |
| Accuracy | ±0.25% |
| Voltage - Supply | 16V |
| Port Size | Male - 0.17" (4.34mm) Tube, Dual |
| Port Style | Barbless |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | 20PSI (137.9kPa) |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP Module |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 5 PSI-D-PRIME-MV | 5 PSI-D-4V | 5 PSI-D-4V-ASCX | 5 PSI-D-4V-MIL |
| Manufacturer | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | SENSOR 5PSID 0.19" .06V | SENSOR 5PSID 0.19" 4.25V | SENSOR 5PSID 0.19" 4.75V 4SIP | SENSOR 5PSID 0.19" 4.25V |
| Series | ACPC | AXCA | ASCX | AXCA |
| Packaging | Tube | Tube | Bulk | Tube |
