Product CatalogPart Number
5120658-2
Manufacturer
TE Connectivity AMP ConnectorsDescription
CONN HEADER DUAL BEAM 100POS PCB
Datasheet
DatasheetPackage
-
In Stock
98,672 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
5120658-2
5120658-2
lmages are for reference only.Payment Methods
Delivery Services
100 Connector Header, Male Pins and Blades Through Hole Dual Beam, Center
Quick Inquiry
5120658-2
Specifications
| Category | Connectors, Interconnects - Backplane Connectors - Specialized |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | Z-PACK HS3 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Connector Usage | Backplane |
| Connector Type | Header, Male Pins and Blades |
| Connector Style | Dual Beam, Center |
| Number of Positions | 100 |
| Number of Positions Loaded | All |
| Pitch | 0.098" (2.50mm) |
| Number of Rows | 10 |
| Number of Columns | 10 |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Contact Layout, Typical | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Color | - |
| Current Rating (Amps) | 1.15A |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -65°C ~ 105°C |
| Voltage Rating | 250V |
| Base Product Number | 5120658 |
